MSI Mainboard MAG B550 TOMAHAWK MAX WIFI - ATX - Socket AM4 - AMD B550 - 7C94-043R
MSI MAG B550 TOMAHAWK MAX WIFI. Prozessorhersteller: AMD, Prozessorsockel: Sockel AM4, Kompatible Prozessoren: AMD Ryzen 3000 Series. Unterstützte Arbeitsspeicher: DDR4-SDRAM, RAM-Speicher maximal: 128 GB, Arbeitsspeicher Typ: DIMM. Unterstützte Speicherlaufwerk-Schnittstellen: SATA III, Unterstützte Speicherlaufwerke: HDD & SSD, RAID Level: 0, 1, 10. Parallele Verarbeitungstechnologie: 2-Way CrossFireX, Maximaler Grafikkartenspeicher: 16000 MB, Maximale Auflösung: 4096 x 2160 Pixel. Ethernet Schnittstellen Typ: 2.5 Gigabit Ethernet, Gigabit Ethernet, LAN-Controller: Realtek RTL8111H, Realtek RTL8125B
Interne Referenz :
194896Barcode :
4719072957957MPN :
7C94-043RWebsite-Produktkategorien :
PC MotherboardsProcessor manufacturer: AMD
Processor socket: Socket AM4
Compatible processors: AMD Ryzen 3000 Series
Maximum number of SMP processors: 1
Supported processor sockets: Socket AM4
Memory
Supported memory: DDR4-SDRAM
Number of memory slots: 4
Memory type: DIMM
Memory channels: Dual-channel
ECC compatibility: ECC & Non-ECC
Supported memory speed: 1866,2133,2400,2667,2800,2933,3000,3066,3200,3466,3600,3733,3866,4000,4133,4266,4400,4533,4600,4733,5100 MHz
Maximum RAM: 128 GB
Unbuffered memory: Yes
Storage controller
Supported storage drives: HDD & SSD
Supported storage drive interfaces: SATA III
RAID Level: 0, 1, 10
Graphics
Maximum graphics card memory: 16000 MB
Parallel processing technology: 2-Way CrossFireX
Maximum resolution: 4096 x 2160 pixels
Internal I/O connectors
Number of USB 2.0 interfaces: 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
SATA III connectors: 6
Front panel audio connector: Yes
ATX power connector (24-pin): Yes
CPU fan connector: Yes
Number of chassis fan connectors: 6
Chassis intrusion connector: Yes
TPM connector: Yes
12 V power connector: Yes
RGB LED header: Yes
Rear I/O connectors
Number of USB 2.0 connectors: 2
USB 3.2 Gen 1 (3.1 Gen 1) number of Type-A connectors: 2
USB 3.2 Gen 2 (3.1 Gen 2) number of Type-A connectors: 1
USB 3.2 Gen 2 (3.1 Gen 2) number of Type-C connectors: 1
Number of Ethernet LAN ports (RJ-45): 2
Number of PS/2 connectors: 1
Number of HDMI connectors: 1
Number of DisplayPort connectors: 1
S/PDIF output: Yes
Optical digital audio output: 1
Network
Ethernet/LAN: Yes
Ethernet interface type: 2.5 Gigabit Ethernet, Gigabit Ethernet
LAN controller: Realtek RTL8111H, Realtek RTL8125B
WLAN: No
Features
Motherboard chipset: AMD B550
Audio chip: Realtek ALC1200
Audio channels: 7.1 channels
Component for: PC
Motherboard form factor: ATX
Motherboard chipset family: AMD
Number of mounting holes: 9
Supported Windows operating systems: Windows 10 x64
Expansion slots
PCI Express x1 (Gen 3.x) connectors: 2
PCI Express x16 (Gen 3.x) connectors: 1
PCI Express x16 slots (Gen 4.x): 1
Number of M.2 (M) slots: 2
BIOS
Clear CMOS jumper: Yes
Weight and dimensions
Width: 305 mm
Depth: 244 mm
Scope of delivery
Included cables: SATA
Drivers included: Yes
| General Information | |
|---|---|
| Marke | MSI |
| Motherboard Chipset | AMD B550 |
| CPU | |
| CPU Manufacturer | AMD |
| Processor Socket | AM4 |
| Memory | |
| RAM Technology | DDR4 |
| Maximum RAM Supported | 128GB |
| Number of RAM Slots | 4 |
| Storage | |
| No. of M.2 Slots | 2 |
